SPECIFICATIONS

Standard Weight - Front: 0 (lbs)

Standard Weight - Rear: 0 (lbs)

Gross Axle Wt Rating - Front: 4100 (lbs)

Gross Axle Wt Rating - Rear: 5360 (lbs)

Curb Weight - Front: 3008 (lbs)

Curb Weight - Rear: 2825 (lbs)

Option Weight - Front: 0.00 (lbs)

Option Weight - Rear: 0.00 (lbs)

Reserve Axle Capacity - Front: 1092.00 (lbs)

Reserve Axle Capacity - Rear: 2535.00 (lbs)

As Spec'd Curb Weight: 5833.00 (lbs)

As Spec'd Payload: 2767.00 (lbs)

Maximum Payload Capacity: 2767.00 (lbs)

Gross Combined Wt Rating: 15000 (lbs)

Gross Axle Weight Rating: 9460.00 (lbs)

Curb Weight: 5833.00 (lbs)

Reserve Axle Capacity: 3627.00 (lbs)

Total Option Weight: 0.00 (lbs)

Payload Weight Front: 0 (lbs)

Payload Weight Rear: 0 (lbs)

Gross Vehicle Weight Rating: 8600.00 (lbs)

TRANSMISSION

Drivetrain: Rear Wheel Drive

Trans Order Code: M5U

Trans Type: 8

Trans Description Cont.: Automatic

First Gear Ratio (:1): 4.56

Second Gear Ratio (:1): 2.97

Third Gear Ratio (:1): 2.08

Fourth Gear Ratio (:1): 1.69

Fifth Gear Ratio (:1): 1.27

Sixth Gear Ratio (:1): 1.0

Reverse Ratio (:1): 3.82

Seventh Gear Ratio (:1): 0.85

Eighth Gear Ratio (:1): 0.65

INTERIOR DIMENSIONS

Passenger Capacity: 12

Front Head Room: 40.85 (in)

Front Leg Room: 41.35 (in)

Front Shoulder Room: 68.85 (in)

Front Hip Room: 65.48 (in)

Second Head Room: 38.42 (in)

Second Leg Room: 36.3 (in)

Second Shoulder Room: 68.6 (in)

Second Hip Room: 65.62 (in)

Third Head Room: 38.5 (in)

Third Leg Room: 36.58 (in)

Third Shoulder Room: 65.75 (in)

Third Hip Room: 63.25 (in)

Fourth Head Room: 38.3 (in)

Fourth Leg Room: 36.58 (in)

Fourth Shoulder Room: 69.1 (in)

Fourth Hip Room: 65.65 (in)

TRAILERING

Dead Weight Hitch - Max Trailer Wt.: 5000 (lbs)

Dead Weight Hitch - Max Tongue Wt.: 500 (lbs)

Wt Distributing Hitch - Max Trailer Wt.: 6700 (lbs)

Wt Distributing Hitch - Max Tongue Wt.: 670 (lbs)

ENGINE

Engine Order Code: LV1

Engine Type: Gas V6

Displacement: 4.3L/262

Fuel System: Direct Injection

SAE Net Horsepower @ RPM: 276 @ 5200

SAE Net Torque @ RPM: 298 @ 3900

Engine Oil Cooler: Yes

ELECTRICAL

Cold Cranking Amps @ 0° F (Primary): 600

Maximum Alternator Capacity (amps): 150

FRAME

Frame Type: Ladder-Type

SUSPENSION

Suspension Type - Front: Independent w/Coil Springs

Suspension Type - Rear: Hypoid Multi-Leaf

Spring Capacity - Front: 4100 (lbs)

Spring Capacity - Rear: 5360 (lbs)

Axle Type - Front: Independent

Axle Type - Rear: Semi-Floating

Axle Capacity - Front: 4100 (lbs)

Axle Capacity - Rear: 5360 (lbs)

Axle Ratio (:1) - Rear: 3.42

Stabilizer Bar Diameter - Front: 1.38 (in)

TIRES

Front Tire Order Code: XLP

Rear Tire Order Code: YLP

Spare Tire Order Code: ZLP

Front Tire Size: LT245/75R16E

Rear Tire Size: LT245/75RR16E

Spare Tire Size: LT245/75R16

Front Tire Capacity: 2060 (lbs)

Rear Tire Capacity: 2680 (lbs)

WHEELS

Front Wheel Size: 16 x 6.5 (in)

Rear Wheel Size: 16 x 6.5 (in)

Spare Wheel Size: 16 x 6.5 (in)

Front Wheel Material: Steel

Rear Wheel Material: Steel

Spare Wheel Material: Steel
